A containerized incinerator with design suitable for use in remote area specifically the oil and gas industry.Incinerator unit should be able to handle common waste with ability to accept small amounts of medical waste,Primary chamber should provide operating temp minimum of 850C; secondary chamber should operate at 1200C with minimum of 2sec residence time.The container shall be fitted with checker plate flooring, fluorescent lighting, complete electrical and safety equipment. Automatic temperature control ON / OFF Operation. PLC Based control panel, digital temperature control. Audio visual alarm system for burner lockout and overload fault, Primary and secondary chamber temperature controllers/indicators, auto controls. electrical control switches, push buttons, relays, contactors, thermocouples, burner sequence controllers, emergency stop, timers, and alarms.
